Overview
XCM CNC balances Nylon and PA machining cost through tolerance grading, material yield, process consolidation, and grade selection instead of treating transmission parts as generic low-cost items. Cheap cnc machining services from a direct factory supplier.
For wear resistance, self-lubrication, gears, sliders, bushings, and metal-replacement work used for weight and noise reduction, the engineering review separates functional fit faces from standard profiles and reduces unnecessary reinspection while still accounting for precision machining and moisture compensation.
Key Capabilities
- Materials: PA6, PA66, MC Nylon, glass-filled Nylon by drawing review
- Tolerance: +/-0.03 mm standard (non-reinforced PA6/PA66), +/-0.005 mm selected critical features by drawing review
- Surface Finish: Ra 3.2 um milled, Ra 1.6 um precision milled, Ra 1.6-2.5 um turned
- GD&T: Coaxiality 0.012 mm, runout 0.01 mm, cylindricity 0.011 mm for selected features by drawing review
- Max Size: Milling 3000 x 1600 x 1400 mm, turning diameter 1250 x 2000 mm
- Surface Treatment: Deburring, edge smoothing, moisture-conditioning review, or marking by drawing review
- Thread: M2-M220, NPT, BSP, G, PT. M1.4 is not recommended for PA because of edge-breakage risk.
- Cost Note: Standard +/-0.03 mm and Ra 3.2 um are included in base machining cost, while tighter specifications are priced separately
Nylon Standard Tolerance Inside Base Machining Cost
Nylon base machining cost can cover standard +/-0.03 mm dimensions on non-reinforced PA6 and PA66, Ra 3.2 um milled faces, standard deburring, and M2-M220 thread machining without extra charges. For gears, sliders, guides, and transmission bushings, the basic route can already include turning, milling, deburring, and normal inspection, while selected +/-0.005 mm precision, Ra 1.6 um milling, and full GD&T verification are quoted separately.
Nylon Surface Roughness Grading for Cost Saving
Nylon roughness grading can separate Ra 3.2 um standard milled faces in the base route, Ra 1.6 um precision milled mating surfaces as an added-cost item, and Ra 1.6-2.5 um turned bores as an added-cost item for selected functional areas only. On gear meshing faces, sliding fits, and bearing bores, that grading keeps cost focused on the surfaces that actually affect wear, fit, and noise.
PA Process Consolidation to Reduce Setup Cost
PA process consolidation can combine roughing, semi-finishing, and inspection in one setup when the drawing datum and feature tolerance allow it, which reduces setup time and fixture cost. For multi-face parts, hole arrays, and fit faces, the one-setup plan still needs drawing review of datum feasibility and moisture compensation before it is accepted.
PA Inspection Scope Optimization for Small Batches
PA inspection-scope optimization can focus CMM time on 0.015 mm position tolerance, 0.012 mm coaxiality, and 0.01 mm hole position for selected functional features instead of full-field overinspection. Small-batch gears, sliders, and transmission parts can keep CMM, roundness, and height-gauge time on critical fit surfaces while standard profiles use caliper or projector sampling.
Specifications
| Product Name | Cheap Nylon (PA) CNC Machined Parts Supplier |
|---|---|
| Manufacturer | XCM CNC |
| Factory Location | Shenzhen, Guangdong, China |
| Quality System | ISO 9001, ISO 13485, IATF 16949, GJB9001C |
| Machining Process | CNC machining |
| Material | Nylon (PA) |
| Material Grade | PA6, PA66, MC Nylon, glass-filled Nylon by drawing review |
| Tolerance | +/-0.03 mm standard (non-reinforced PA6/PA66, included in base cost) |
| Precision Tolerance | +/-0.005 mm selected critical features by drawing review, priced separately |
| Surface Roughness | Ra 3.2 um milled in base cost, Ra 1.6 um precision milled as added cost, Ra 1.6-2.5 um turned as added cost for functional areas |
| Surface Treatment | Deburring, edge smoothing, moisture-conditioning review, or marking by drawing review |
| Max Part Size | Milling 3000 x 1600 x 1400 mm / Turning diameter 1250 x 2000 mm |
| Inspection | CMM, roundness tester, height gauge, roughness tester, thread gauges, with scope optimized by drawing review |
| Application | Cost-balanced wear strips, prototype gears, low-noise motion details |
| Typical Application | Cost-controlled nylon wear parts |
| Key Features | Wear-resistant PA machining, tolerance grading, surface grading, process consolidation, inspection-scope optimization |
| Critical QC Requirements | Material traceability, moisture-expansion review, tooth-profile inspection, fit-surface check, post-process reinspection |
| Batch Range | 1 piece to planned repeat batches |
| MOQ | 1 Piece |
| Typical Lead Time | 10-15 business days after drawing review |
| Drawing Formats | STEP, IGS, DWG, PDF, X_T |
| Secondary Process | Deburring, edge smoothing, moisture-conditioning review, marking, and post-machining reinspection |
| Material Certificate | Material certificate by order requirements |
| Material Feature | Wear-resistant polymer, low-noise motion parts, moisture-compensation review |
| Critical Tolerance Control | Flatness 0.02 mm, position tolerance 0.015 mm, hole position 0.01 mm by drawing review |
Applications
PA Gear Programs with Cost Grading
Typical Parts: Plastic gear, worm gear, transmission bushing
PA gear cost can be graded by function, keeping tooth forms and fit bores at selected +/-0.005 mm precision with Ra 1.6 um surfaces while outer profiles and nonfunctional faces remain at standard +/-0.03 mm and Ra 3.2 um. The standard route already includes turning, milling, deburring, and common inspection, while gear-profile validation and reinforced materials are still separate-cost items.
Textile Sliders with Consolidated Operations
Typical Parts: Yarn guide, wear slider, cam
PA slider cost can be reduced by combining guide-groove milling, sliding-face finishing, and deburring in one setup to avoid repeated datum transfer. Standard machining already covers the basic tolerance and finish route, while sliding surfaces that need Ra 1.6-2.5 um or 0.012 mm coaxiality still require separate evaluation against the drawing and fixturing feasibility.
Food-Equipment Rails with Optimized Inspection Scope
Typical Parts: Wear guide rail, chain plate, guide part
PA rails and chain plates can control cost by focusing CMM time on guide-face flatness and chain-hole position while leaving standard profiles on caliper sampling. Full GD&T validation, batch traceability, and third-party reporting are still separate-cost items confirmed by drawing and acceptance standard.
Conveyor Sprockets with Layered Material Selection
Typical Parts: Conveyor slide rail, guide strip, sprocket
PA sprocket and guide-strip programs can grade material selection between PA6 or PA66 for cost and MC Nylon or glass-filled grades for higher wear demand, instead of forcing the highest-grade material onto every project. Tool-wear compensation, fiber-direction control, and fit-face checks for reinforced grades still need separate review.
Why Choose Us
Certified Quality System and Nylon Machining Coverage
XCM CNC organizes Nylon and PA projects under ISO 9001, ISO 13485, IATF 16949, and GJB9001C aligned quality processes, with DMG, Mazak, Matsuura, and Brother equipment supporting turning, milling, and wear-resistant transmission parts. PA6, PA66, MC Nylon, and glass-filled projects can review moisture compensation, gear precision, and wear-surface requirements during drawing review.
Size Range from Small Connectors to Large Wear Structures
The machining range covers small connector-scale parts, PA gears, sliders, bushings, low-noise transmission parts, larger guide rails, conveyor wear parts, and metal-replacement weight-saving structures. Milling travel reaches 3000 x 1600 x 1400 mm and turning capacity reaches diameter 1250 x 2000 mm, subject to fixturing, moisture compensation, material grade, and fit requirements.
Tiered Equipment Strategy for Low-Cost CNC Machining, Quality-Assured Production
XCM CNC uses four equipment tiers from mainland China, Taiwan, Japan, Europe, and the US. Standard-tolerance operations can run on domestic or Taiwan equipment, while higher-precision features move to imported machines such as DMG and Mazak. Equipment is matched to actual tolerance needs so cost stays aligned with the drawing.
Transparent Tolerance and Surface-Cost Grading
The standard route already includes +/-0.03 mm on non-reinforced PA6 and PA66 and Ra 3.2 um standard milled faces. Functional areas that need selected +/-0.005 mm precision, Ra 1.6 um precision milling, or Ra 1.6-2.5 um turned finish can be marked as separate-cost items in quotation so there is no hidden overprocessing.
Consolidated Operations and Optimized Inspection
For prototypes and small batches, one-setup multi-face machining and focused CMM time on key fit faces can reduce overall cost structure. Datum feasibility and moisture compensation still need review during drawing evaluation so cost reduction does not create functional risk.
