Overview
XCM CNC provides OEM alloy steel CNC turning and milling for build-to-print parts that need higher load capacity and fatigue strength, using imported equipment from brands such as DMG and Mazak under ISO 9001 and IATF 16949 based quality systems.
For grades such as 42CrMo, 40Cr, and 20CrMnTi, we review the drawing first to confirm load targets, heat treatment routing, MOQ from 1 piece, and a standard lead time of 10-15 days. For shafts, gear blanks, couplings, and hydraulic parts, the sample stage is used to confirm heat treatment sequence, stock allowance before and after quench and temper, keyway or spline datums, and fit-critical shaft and bore requirements before pilot delivery and repeat production planning.
Key Capabilities
Machining Parameters
- Materials: 40Cr, 42CrMo, 20CrMnTi, GCr15
- Tolerance: +/-0.003 mm (+/-0.00012 inch), IT5 or IT6 accuracy, +/-0.01 mm shaft and bore fits, with h6 and H7 available
- Surface Finish: Ra 3.2 um milled, Ra 1.6 um precision machined, Ra 0.8 um turned or bored
- GD&T: Coaxiality 0.012 mm, runout 0.01 mm, cylindricity 0.011 mm
- Max Size: Milling 3000 x 1600 x 1400 mm, turning diameter 1200 x 2500 mm
- Heat Treatment: Quench and temper, carburizing, nitriding
- Thread: M1.4-M220, NPT, BSP, G, PT
- Inspection: CMM dimensional report, FAI report, and material certificate by order requirement
Alloy Steel Shaft and Bore Fit Tolerance for OEM Assembly
OEM alloy steel parts with shaft and bore fits are commonly machined to h6 and H7 classes, with shaft diameter tolerance controlled around +/-0.005 to 0.01 mm and coaxiality of fit surfaces around 0.012 mm. These values cover transmission shafts, couplings, and reducer bearing seats, while the same fit faces are commonly held around Ra 0.8 um.
Multi-Process Turning and Milling for Transmission Parts
Alloy steel transmission parts often need combined turning and milling. Turning up to diameter 1200 mm and length 2500 mm covers long shafts and large flanges, while keyways can start from 1.0 mm width and thread sizes can range from M1.4 to M220. Slender shafts up to L/D 15:1 can be reviewed with steady rests and follower supports to control distortion.
GD&T Control on Structural and Rotating Components
Geometric tolerances are controlled to the drawing datum system. Typical values include circular runout 0.01 mm, total runout 0.012 mm, perpendicularity 0.02 mm/1000 mm, and position 0.015 mm. Mounting face parallelism can be controlled within 0.03 mm over a 1030 mm datum length for multi-face assemblies and flange connections.
Inspection Documentation for OEM Alloy Steel Orders
OEM orders can be supported with CMM dimensional reports, FAI reports, and material certificates. Threads can be checked by go and no-go gauges or ring gauges, and critical dimensions with cosmetic requirements can be inspected item by item. Report format can follow the customer template, while heat treatment reports and salt spray reports are supplied when specified by order.
Specifications
| Product Name | OEM Alloy Steel CNC Turned and Milled Parts |
|---|---|
| Manufacturer | XCM CNC |
| Factory Location | Shenzhen, Guangdong, China |
| Quality System | ISO 9001, ISO 13485, IATF 16949, GJB9001C |
| Machining Process | CNC turning, CNC milling, turn-mill machining, drilling, tapping |
| Material | Alloy Steel |
| Material Grade | 42CrMo, 40Cr, 20CrMnTi selected by load and heat treatment route |
| Tolerance | +/-0.03 mm standard CNC tolerance, critical dimensions by drawing review |
| Precision Tolerance | +/-0.003 mm for selected small precision features after review |
| Surface Roughness | Ra 1.6 um machined surfaces, Ra 0.8 um fit bores or sealing surfaces by requirement |
| Surface Treatment | Heat treatment, rust preventive oil, black oxide, or plating by drawing review |
| Inspection | Dimensional inspection, FAI, heat treatment report, and CMM for critical features by order requirement |
| Application | Transmission shafts, gear blanks, couplings, hydraulic rods, heavy-duty pins |
| Key Features | Shaft-bore fits, keyways or splines, heat treatment allowance, heavy-load chamfers, flange hole patterns |
| Critical QC Requirements | Datum transfer before and after heat treatment, coaxiality check, key dimension recheck, report coordination |
| Batch Range | Prototype samples to repeat production by drawing review |
| MOQ | 1 Piece |
| Typical Lead Time | 10-15 business days after drawing review |
| Drawing Formats | STEP, IGS, DWG, PDF, X_T |
| Heat Treatment | By drawing review |
| Critical Tolerance Control | Key fit features reviewed before and after heat treatment |
Applications
Custom Gear Blanks, Spline Shafts, and Couplings
Typical Parts: Gear blank, spline shaft, coupling
Alloy steel suits transmission parts that need higher load capacity and fatigue strength, and the drawing review stage can confirm whether 40Cr, 42CrMo, or 20CrMnTi is the right match together with the heat treatment route. CNC turn-mill machining helps keep shaft diameters, keyways, and end-face datums in one controlled process, then design changes can be handled after sample approval.
Automotive Powertrain Shafts and Connection Parts
Typical Parts: Drive shaft, connector sleeve, mounting flange
These parts typically focus on torque transfer, shaft and bore fit, and dimensional stability after heat treatment. Alloy steel is better suited than ordinary carbon steel for alternating loads. CNC machining can split rough machining, quench and temper, and finish machining according to the drawing, while the exact application requirement still depends on the customer drawing, service condition, and industry rules.
High-Strength Pins, Hydraulic Rods, and Brackets for Construction Equipment
Typical Parts: Heavy-duty pin, hydraulic rod, link bracket
Construction equipment parts need to balance impact loading, wear-resistant fit faces, and rust protection. Alloy steel can raise load capacity through the right grade and heat treatment choice. Turning, milling, and drilling routes can be reviewed around assembly bores, chamfers, and lubrication grooves to reduce rework risk during the sample stage.
Main Shaft Flanges and Couplings for Wind Power and Heavy Energy
Typical Parts: Main shaft flange, heavy-duty coupling, end cover ring
Large flanges and couplings often require material lot confirmation, heat treatment reports, and fixturing plans to be aligned together. Alloy steel is suitable for long-term high-load assembly work. CNC machining can evaluate hole patterns, end faces, and outer diameter stock to the drawing, while final delivery conditions still depend on the blank condition and inspection scope.
Why Choose Us
Qualified Systems and Equipment Coverage
XCM CNC can organize projects to ISO 9001, ISO 13485, IATF 16949, and GJB9001C system requirements, while arranging machining routes across DMG, Mazak, Matsuura, Brother, and other equipment brands. For OEM alloy steel parts, that structure helps place heat treatment, critical fits, and reinspection requirements into one coordinated communication flow.
Broad Size Range for Rotating and Structural Parts
We support machining from small connector-scale parts to large structural components, with three-axis travel up to 3000 x 1600 x 1400 mm and turning diameter up to 1250 mm. For shafts, couplings, and flange-type alloy steel parts, this range helps align rough machining, heat treatment, and finish machining within the same supply rhythm.
Tiered Equipment Strategy for Cost and Quality
XCM CNC uses a tiered equipment strategy that includes mainland China, Taiwan, Japan, and Europe or US sourced CNC machines. Lower-tolerance operations can run on domestic or Taiwan equipment, while tighter precision work can move to imported machines such as DMG and Mazak. That matching helps control cost without placing simple features onto high-hour equipment unnecessarily.
Transmission Datums Confirmed Early
For gear blanks, shafts, and coupling structures, we confirm shaft and bore datums, keyway direction, and the sequence around later heat treatment before the sample is made. That is more effective for OEM alloy steel projects that require turn-mill processing and revision control than trying to add datum definitions later.
Heat Treatment Allowance Communication
Finish machining after carburizing, nitriding, or quench and temper directly affects the final result of high-load and high-precision transmission parts. We use the sample stage to confirm stock allowance, reinspection points, and rust protection requirements so the alloy steel project is closer to the final production route before batch release.
FAQ
What drawing files do you need for custom alloy steel turned and milled parts?
We usually need STEP, IGES, STP, DWG, or a dimensioned PDF together with the material grade, quantity, critical tolerances, and application notes. If the part involves heat treatment, carburizing, nitriding, or a forged blank, that should also be stated during quotation review.
Can you review 42CrMo, 40Cr, or 20CrMnTi before machining a custom alloy steel part?
Yes. 42CrMo is usually more suitable for higher-load structures, 40Cr is common for general high-strength transmission parts, and 20CrMnTi is often selected for carburizing routes. Final grade selection still needs to be confirmed from load, heat treatment, and cost requirements.
How do you arrange machining before and after heat treatment on alloy steel parts?
We normally confirm rough-machining allowance, heat treatment sequence, and the finish-machining areas first, then decide the final process route. For shaft and bore fits, splines, and heavy-load faces, that step directly affects consistency between the sample and later production.
What is the lead time for custom alloy steel CNC parts?
Sample lead time is often reviewed in the 3-7 day range, while standard batch lead time is typically 10-15 days depending on part complexity and the heat treatment cycle. For carburized or nitrided parts, outside heat treatment time needs to be added separately.
What is the MOQ for OEM alloy steel machined parts?
MOQ starts from 1 piece and supports single-piece samples through to batch production. Batch conversion is arranged after sample approval, and the sample should pass confirmation before the production run is released.
What payment and shipping methods do you support?
Payment can be arranged by T/T, PayPal, or Western Union. Shipping can use DHL, FedEx, UPS, or sea freight, with foam plus carton or wooden-case packaging selected by part size and rust protection needs. NDA support is available for drawing confidentiality.
