Custom Precision Aluminum 5-Axis Machined Parts

Custom Precision Aluminum 5-Axis Machined Parts

Material: Aluminum MOQ: 1 piece Tolerance: +/-0.003 mm on precision features, IT5/IT6, h6/H7 fits, freeform profile 0.02 mm Lead Time: Prototype 3-7 days; production 10-15 days depending on complexity and quantity
Email: [email protected] | WhatsApp: +8618638951317

Overview

XCM CNC machines custom precision aluminum 5-axis parts in Shenzhen, including freeform surfaces, thin blades, angled holes and mounting faces in multiple orientations on impellers, curved housings, gimbal mounts and angled brackets. Complex surfaces are machined to 3D models with surface profile tolerance down to 0.02 mm. Critical surfaces and precision features are machined on imported machining centers from DMG, Matsuura and other manufacturers. Polishing, sandblasting and anodizing are also available.

Aluminum alloys are lightweight and easy to machine, making them suitable for lightweight structures. Electronic housings can also use aluminum’s thermal conductivity. The factory is certified to ISO 9001, ISO 13485, IATF 16949 and GJB9001C. Orders start at one piece. Prototypes typically take 3-7 days and production typically takes 10-15 days, depending on part complexity and quantity.

custom aluminum 5 axis machined parts

Key Capabilities

  • Materials: Aluminum 6061, 7075, and customer-specified 6xxx/7xxx grades and tempers
  • Tolerance: +/-0.003 mm (+/-0.00012 inch), IT5 or IT6 accuracy, +/-0.01 mm shaft/bore fits; h6/H7 available
  • Surface Finish: Standard milled faces Ra 3.2 um; finish-milled mounting and contact faces Ra 1.6 um; polished faces Ra 0.2 um; precision polishing on critical areas down to Ra 0.015 um (by drawing review)
  • GD&T: Freeform surface profile 0.02 mm against the 3D CAD model; position 0.015 mm; flatness 0.02 mm; perpendicularity 0.02 mm / 1000 mm
  • Max Size: 5-axis machining capacity 800 x 600 x 900 mm, subject to machine travel, fixturing, and part orientation
  • Surface Treatment: Anodizing 8-15 um; hard anodizing 25-60 um; sandblasting 80#-220#; mirror, bright, or matte polishing (confirmed by order)
  • Thread: M1.4-M220 (internal from M1.4, external from M2.0); NPT / BSP / G / PT pipe threads
  • Precision Limit: +/-0.003 mm dimensional tolerance, 0.006 mm roundness, 0.01 mm hole-pattern position (specific features, by drawing review)

custom aluminum 5 axis machined parts

5-Axis Aluminum Freeform Surface Machining with 0.02 mm Profile Tolerance

Complex freeform aluminum surfaces can achieve a surface profile tolerance of 0.02 mm, evaluated against the 3D CAD model and specified datums. Finish-milled surface regions can achieve Ra 1.6 um, while areas with higher appearance requirements can be polished to Ra 0.2 um. Surface profiles are measured with a Hexagon Inspector Classic 06.08.06 CMM. Complex parts can also undergo 3D scanning or profile inspection.

Aluminum Impeller 5-Axis Machining: 800 mm Diameter and 0.6 mm Blades

Five-axis aluminum impeller machining supports diameters up to 800 mm and blade thicknesses down to 0.6 mm. Blade tips have the lowest stiffness along the blade. Layered cutting and tool orientation adjustments help control chatter and deformation. Blade surfaces are evaluated to a 0.02 mm profile tolerance, and blade thickness and inter-blade passages are inspected with a CMM.

Aluminum Angled Hole and Compound-Angle Face Machining with 0.015 mm Position

Angled holes and spatial mounting faces on aluminum brackets and gimbal mounts are machined using 3+2-axis positioning or simultaneous 5-axis machining. Hole position tolerance is 0.015 mm and perpendicularity is 0.02 mm / 1000 mm. Countersinks have a 90 degree angle with a +/-0.1 degree angular tolerance. A CMM checks hole positions and angled faces against drawing datums. Step heights can be cross-checked with a TRIMOS 600L height gauge.

Aluminum Undercut and Deep-Cavity Machining: 4:1 Aspect Ratio, R1.0 mm Corners

Aluminum housing cavities support a depth-to-width ratio of 4:1, extending to 5:1 with longer tools. For a 40 mm deep cavity, an internal corner radius of at least R1.0 mm is recommended. The minimum internal radius achievable with an end mill is R0.5 mm. Undercuts that remain inaccessible after reorienting the part for 5-axis machining can be made with special tools, multiple setups or EDM. Fully sharp internal corners require EDM or a design change.

Specifications

Product Name Custom Precision Aluminum 5-Axis Machined Parts
Manufacturer XCM CNC
Factory Location Shenzhen, Guangdong, China
Quality System ISO 9001, ISO 13485, IATF 16949, GJB9001C
Machining Process 5-Axis CNC Machining
Material Aluminum
Material Grade 6061, 7075, customer-specified 6xxx/7xxx grade and temper
Tolerance +/-0.003 mm on precision features, IT5/IT6, h6/H7 fits, freeform profile 0.02 mm
Surface Roughness Ra 3.2 / 1.6 / 0.2 um; Ra 0.015 um precision polishing on critical areas only
Surface Treatment Polishing (mirror/bright/matte), sandblasting 80#-220#, anodizing 8-15 um, hard anodizing 25-60 um, color per color chart, according to order requirements
Max Part Size 800 x 600 x 900 mm, subject to fixturing and part orientation
Inspection CMM, 3D scan, profile inspection, dimensional inspection report; Inspection equipment: Hexagon Inspector Classic 06.08.06, Leader NCA8106, WanHao Rational VMS-3020G 2.5D video measuring machine, TRIMOS 600L height gauge
Application Aluminum impellers, curved housings, lightweight angled brackets, gimbal mounts
Key Features Freeform surfaces, thin blades, angled holes, multi-directional faces, undercut features
Critical QC Requirements CAD-based profile, blade thickness, datum-based feature orientation, specified appearance
MOQ 1 piece
Typical Lead Time Prototype 3-7 days; production 10-15 days depending on complexity and quantity
Drawing Formats STEP, IGES, STP, DWG, PDF with dimensions

Applications

5-Axis Aluminum Impellers for Industrial Blowers

Typical parts: Blower Impeller, Centrifugal Impeller

Curved impeller blades and inter-blade passages require machining along three-dimensional geometry. Five-axis machining provides access to blade surfaces from different directions. Lightweight aluminum impellers can reduce rotor weight in industrial blowers and air-handling equipment.

Relevant capabilities: Maximum impeller diameter 800 mm, minimum blade thickness 0.6 mm and surface profile tolerance 0.02 mm.

Contoured Aluminum Robot Joint Housings and Brackets

Typical parts: Contoured Joint Housing, End Effector Bracket

Compact joint housings must accommodate drive components, while end effector brackets connect tools or sensors facing different directions. Aluminum structures can reduce the weight of moving robot components.

Relevant capabilities: Curved outer walls and angled mounting holes machined on the same part, hole position tolerance 0.015 mm and minimum metal wall thickness 0.5 mm.

Aluminum Camera Gimbal Housings and Multi-Angle Mounts

Typical parts: Gimbal Housing, Multi-Angle Adjustment Mount

Gimbal housings combine curved shapes with support interfaces in multiple directions and clearance features. Lightweight aluminum parts suit camera support mechanisms that require frequent movement and adjustment.

Relevant capabilities: 3+2-axis or 5-axis machining of support faces at different angles, perpendicularity 0.02 mm / 1000 mm and 5-axis machining capacity 800 x 600 x 900 mm.

Curved Aluminum Housings for Electronics and Communications

Typical parts: Curved Heat Sink Housing, Sensor Housing with Angled Interfaces

Limited equipment space often calls for curved housings and angled interfaces. Aluminum housings can serve as thermal paths and shielding enclosures. Curved exterior surfaces can be polished, sandblasted and anodized.

Relevant capabilities: Thermal contact face flatness 0.02 mm, minimum fin thickness 0.8 mm, minimum fin spacing 1.0 mm and standard anodizing thickness 8-15 um.

Aluminum Mounting Structures for UAV and Satellite Equipment

Typical parts: Contoured UAV Bracket, Satellite Equipment Mount

Connection holes in multiple directions, inclined mounting faces and contoured weight-reduction features suit compact equipment mounting structures. Aluminum alloys offer low weight and high strength-to-weight ratios for lightweight designs. Suitability for specific UAV and satellite projects is evaluated against drawings and project requirements.

Relevant capabilities: Minimum weight-reduction rib thickness 0.8 mm, rib height-to-width ratio 8:1 and internal threads starting at M1.4.

Why Choose Us

Equipment and Quality Systems for Complex Parts

XCM CNC operates DMG 80mono, Matsuura MX-520, Mazak I-100S and Brother machining centers for complex aluminum parts and associated features. Its quality systems include ISO 9001, ISO 13485, IATF 16949 and GJB9001C.

Supporting Operations from Small Connectors to Large Structural Parts

The machining range covers small connectors through large structural parts. Curved parts can include hole machining, threading, edge breaking and necessary secondary operations. Finished surfaces can be polished, sandblasted or anodized, allowing you to source parts that meet both structural and appearance requirements from one supplier.

Tiered Equipment Strategy for Low-Cost CNC Machining, Quality-Assured Production

XCM CNC groups its CNC equipment into four tiers: mainland China, Taiwan, Japan, and Europe and North America. Lower-tolerance operations such as roughing and general hole machining use mainland Chinese or Taiwanese equipment. Surface finishing and precision mating features use imported machines such as DMG and Mazak. Equipment is matched to each part’s actual accuracy requirements, so machines with higher hourly costs are reserved for demanding operations, reducing machining costs while meeting drawing requirements.

Prototype First Article Approval before Production

Five-axis aluminum parts begin with prototypes, typically completed in 3-7 days. A first article inspection (FAI) report is prepared in the customer’s requested format, accompanied by a CMM report and material certificate. Production starts after customer approval. Third-party inspection reports can be arranged separately. An NDA can be signed before quotation for drawings containing confidential designs.

Visible Curved Surfaces Accepted against Color References and Approved Samples

Colors on visible parts such as gimbal housings and electronic enclosures are checked against the customer’s specified color reference numbers. Surface texture, scratches and color variation are assessed against customer appearance standards or a reference sample approved by both parties. Production batches are compared with the same approved sample to reduce appearance variation between batches.

FAQ

How should tolerances be specified for a curved aluminum 5-axis part?

Specify surface profile tolerance for curved geometry using ISO 1101 or ASME Y14.5, with the 3D model defining the theoretical shape and the datums clearly identified. Specify dimensional and position tolerances separately for mounting holes, mating features and contact faces. Complex surface profile capability is 0.02 mm, while dimensional tolerance on precision features is +/-0.003 mm. These requirements are inspected separately.

Does hard anodizing change the size of precision holes on 5-axis aluminum parts?

Yes. Hard anodizing is 25-60 um thick and standard anodizing is 8-15 um thick. The coating changes hole diameters and mating dimensions. H7 bores and threads usually require masking or coating allowance during machining. State whether drawing dimensions apply before or after anodizing. Compensation is calculated from coating thickness and the fit class.

Can I order a single aluminum 5-axis prototype before production?

Yes. The minimum order is one piece, and parts can be customized from drawings or samples. Prototypes typically take 3-7 days. Customer sample approval is required before production, and a dimensional inspection report is supplied with the sample.

What is the production lead time after the aluminum sample is approved?

After sample approval, standard production typically takes 10-15 days. Parts with multiple curved surfaces, such as impellers, require more machining time. The specific lead time is evaluated at quotation based on part complexity and order quantity.

What files should I send for a five-axis machining quote?

Send a 3D surface model and a 2D drawing specifying material, quantity, datums, critical profiles, appearance requirements and intended use. Accepted formats include STEP, IGES, STP, DWG and dimensioned PDF files. An NDA can be signed as required for confidential designs.

What payment, shipping and packaging options are available for 5-axis aluminum parts?

Payment options include T/T, PayPal and Western Union. Shipping options include DHL, FedEx, UPS and sea freight. Standard packaging uses foam and cartons. Thin-bladed impellers and parts with visible curved surfaces are individually separated with foam to reduce shipping damage. Wooden crates can be used on request for large or heavy parts.

What alloy information is needed for a lightweight angled bracket?

Specify the aluminum grade and temper, structural application, critical fits and surface treatment requirements. Customer-specified 6xxx or 7xxx aluminum alloys can be used. Material certificates allow the delivered material to be checked against the specified alloy.
